Fig. 4
Download original image
(a) Details of the newly developed tooling system attached on the machine tool, showing 3D printed jig, driving wheel and wheel type finishing tool, (b) load cell position inside the machine H-axis and probing arrangement with standard SAG tools and new wheel tool, and (c) probing points selected inside the channel and captured error map with residual error.
