(a) PVC irradiations at 515 nm with N = 150 pulses/spot-area and f = 10–45 kHz increasing from left to right. (b) PVC irradiations at 313 nm with N = 150 pulses/spot-area and f = 15–100 kHz increasing from left to right. (c) PVC 1 MHz irradiation with N = 150 pulses/spot-area and 515 nm. (d) PVC 1 MHz irradiation with N = 150 pulses/spot-area and 343 nm. (e) PVC measured irradiated lines ablation depth, ablation diameter and extended diameter for N = 150/spot-area at 515 nm as functions of repetition rate. (f) PVC measured irradiated lines ablation depth, ablation diameter and extended diameter for N = 150/spot-area at 343 nm as functions of repetition rate. All the presented irradiations were performed at a fluence value of 1.40 J/cm².
